Electric Bike 24v Battery Pack

1）Battery Pack：76.8V110Ah

2）Maximum Size：550*243*280mm



2.1 Battery pack structure



2.2 Battery pack parameter

No.	Item	Parameter	Remarks
1	Rated Voltage	76.8V
2	Rated Capacity	110Ah
3	Working voltage range	63.5-87.6V	Can be customized
4	Discharge temperature range	-10-55℃
5	Charge temperature rang	0-50℃
6	Charging Current(Recomm)	30A
7	Charge voltage	87.6V
8	Discharge Current(Recomm)	60A	Can be customized
9	Instant discharging current	150A
10	Life cycle time	3000 times
11	Operating humidity	<80%RH



To prevent the possibility of the battery from leaking, heating, explosion, please observe the following

precautions:

Don’t immerse the battery in water;

Don’t use and leave the battery near a heat source such as fire or heater;

When charging, use a battery charger specifically for that purpose;

Don’t reverse the positive and negative terminals;

Don’t discard the battery in fire or heater;

Don’t connect the battery to an electrical outlet directly;

Don’t discard the battery in fire or heater;

Don’t connect the positive and negative terminal directly with metal objects;

Don’t transport and store the battery together with metal objects such as necklaces, hairpins;

Don’t pierce the battery with a nail or other sharp object.



The capacity of delivery battery is approximately at 50% of charging. During the transportation, keep the battery away from acutely vibration, impacting, polarization, drenching.



5.1 Battery status: zero state of battery is strictly prohibited during storage, battery voltage during storage should keep 30-60% SOC;

5.2 Storage conditions: keep the place clean and dry; keep the battery pole clean and no pollution; do not place heavy or liquid containing containers on battery; storage place should without flammable, explosive, toxic things such as chemical and other corrosive gases, no strong mechanical vibration and shock, avoid the strong electromagnetic field and the sun exposure. Suggested storage conditions are as follows:

Temperature	Best temperature	Humidity	Atmospheric pressure
-10~35℃	15~30℃	20~80%RH	90~105kPa



6.1 Short-term storage (1 month) of the battery, check the temperature and humidity of the storage place weekly, check the battery for any abnormalities such as leakage. Before using, measure the voltage and charge if below 76.8V.

6.2 Long-term storage (more than 2 months) of the battery, check the temperature and humidity of the storage place weekly, check the battery for any anomalies such as leakage. Every 3 months do the charge and discharge action (recommended 0.2C). Before using, measure voltage, if less than 72V, should charge battery firstly.





Why choose us?

• Our factory is geared towards delivering high-quality products and services that exceed our customers' expectations.
• We promote the team spirit of unity and cooperation to create harmony within the enterprise and form a strong driving force for its development.
• Our Ebike Batteries are designed to provide optimum performance, reliability, and energy efficiency.
• We plow through a number of fast-growing categories, offering unique Electric Bike 24v Battery Pack that foster innovation to address current and future trends.
• We pride ourselves in providing top-notch products and services to our customers.
• We are committed to creating a corporate atmosphere where compliance creates value and provides a guarantee for sound operation and sustainable development of the company.
• We provide fast, efficient, and reliable order processing, delivery, and support services to our customers.
• We provide a platform for the growth of talents, so that they can become a powerful support for the sustainable development of the enterprise, and realize the common growth and development of the enterprise and talents.
• Our Ebike Batteries are designed to be energy-efficient, eco-friendly, and highly cost-effective.
• Looking forward to the future, we will continue to uphold the business philosophy of honest management and promise.

Electric Bike 24v Battery Pack - Powering Your Ride With Efficiency and Reliability



Introducing our latest product - the Electric Bike 24v Battery Pack, designed to provide you with a seamless and efficient riding experience. Made with premium materials and latest technology, our battery pack is built to provide long-lasting, durable performance that will power your ride for long distance and steep terrain.



Why Choose Our Electric Bike 24v Battery Pack?

Quality and Durability

Our battery pack is made with high-quality cells, providing a long lifespan and sustainable performance. The cells used in our battery pack are sourced from renowned manufacturers, ensuring their quality, reliability, and safety. The pack is also made using advanced technology that guarantees its stability, durability, and performance even in harsh weather conditions.



Reliable and Safe Performance

Safety is our top priority, and our battery pack is designed to provide reliable and safe performance. It has built-in protection mechanisms to prevent overcharging, over-discharging, short-circuiting, and over-heating. The pack also features advanced temperature control technology that ensures that the battery stays within optimal temperature limits, preventing damage to the battery in extreme weather conditions.



Strong Power Output

Our battery pack is built to cater to the energy needs of different electric bikes. With a 24v power output, it can provide enough power to enable your ride to reach up to faster speeds and climb steep terrain with ease. It has a capacity of up to 10Ah, making it an ideal choice for long-distance commutes, outdoor excursions, and adventures.



Efficiency and Convenience

Our battery pack is equipped with advanced Energy Management System technology that ensures maximum efficiency and convenience. The system regulates the power to ensure that the rider gets the most out of the battery without compromising on performance. For added convenience, the battery is easy to install on any compatible electric bike model, and it comes with a charger that can quickly refill the battery whenever you need it.



Eco-Friendly and Sustainable

Our Electric Bike 24v Battery Pack is an ideal investment for those who value sustainability and eco-friendliness. An electric bike using our battery pack produces zero emissions, providing a more eco-friendly means of transportation. The battery is also built to last and can sustain a large number of recharge cycles, reducing the need for regular replacements and minimizing waste.



Conclusion

In conclusion, our Electric Bike 24v Battery Pack is a reliable and efficient solution for powering your ride. Its quality and durability, reliable and safe performance, strong power output, efficiency and convenience, and eco-friendliness make it a great choice for outdoor enthusiasts, commuters, and cyclists worldwide. Our battery packs are available at wholesale prices, and we look forward to working with merchants worldwide to provide quality and reliable power solutions that meet and exceed their needs.
